Aqara
Aqara Smart Wall Switch H1 (No Neutral, Double Rocker)
- Zigbee
Verified September 2026
The default pick for older UK back boxes with no neutral wire — despite the box saying it needs the Aqara Hub, it's a plain Zigbee 3.0 device that pairs directly into Zigbee2MQTT or ZHA. At 85.8 x 86 x 37.55mm it shares its with-neutral sibling's body, so budget a back box at least 35mm deep — shallow 25mm UK boxes are a squeeze. Max load is 8A resistive, but Aqara doesn't publish a minimum: very low-draw LEDs under roughly 3W per gang need anti-flicker mode to stop ghost-glow. ZHA support is thinner than Zigbee2MQTT's (no decoupled/scene mode), so Zigbee2MQTT is the better path for remote-style use.
In Home Assistant
| Control | Type | What it does |
|---|---|---|
| Switch (left) | Switch | On/off/toggle relay control for the left gang; no power or energy readback on this no-neutral variant. |
| Switch (right) | Switch | On/off/toggle relay control for the right gang; no power or energy readback on this no-neutral variant. |
| Operation mode | Select | Per-button control-relay or decoupled setting, independent per gang; decoupled frees the physical rocker from its relay so it can drive automations instead. |
| Button action | Event | Fires single/double click events per button — only usable for scene/remote-style automations when the corresponding button is set to decoupled. |
| Mode switch | Select | Quick or anti-flicker — anti-flicker slows relay switching to suppress flicker/glow on LED loads caused by the bleeder current this no-neutral switch draws to stay powered. |
Because this no-neutral variant borrows a small bleeder current through the connected load to stay powered, Zigbee2MQTT exposes a mode switch (quick vs anti-flicker) specifically to fix LED flicker or ghost-glow on lights that draw too little standby current — a setting the with-neutral H1 doesn't need. It also drops the with-neutral model's power/energy metering entirely and isn't listed as a mesh router, since no-neutral devices can't sustain the constant draw that routing requires. With operation mode set to decoupled on one gang, a single/double click can drive a different Home Assistant light or scene while that gang's relay stays inert — useful for turning the second rocker on a double plate into a dedicated scene button when only one physical circuit is wired.
Specs
- gangs
- 2
- max load
- 8A resistive (~1,840W at 230V)
- min load
- Not officially published by Aqara — LED/CFL loads under roughly 3W per gang risk flicker on the bleeder circuit; use the anti-flicker mode switch if this happens
- protocol
- Zigbee 3.0
- dimensions mm
- 85.8 x 86 x 37.55 (W x H x D)
- rated voltage
- 100-250VAC, 50/60Hz
- zigbee router
- false
- back box depth
- 37.55mm module depth — needs a back box at least 35mm deep; standard shallow 25mm UK boxes typically won't fit without a spacer
- neutral required
- false
- wall box compatibility
- Round or 86mm square European back boxes
