Shelly 1L Gen3 (with Bypass)
- Wi-Fi
- Matter
- Bluetooth
Verified September 2026
Shelly's dedicated answer to the classic UK no-neutral lighting circuit: a live-only single relay, with the bypass capacitor built in so LED loads under 5W stay happy. Same fully-local Shelly integration as the rest of the range — no compromise on control quality just because your back box lacks a neutral. At £26.24 it's roughly double SONOFF's ZBMINIL2 (£13.99) — pay the premium if you want Wi-Fi's simpler pairing and Shelly's polished app/HA integration over Zigbee's better mesh scaling and lower per-device draw. At 37x42x16mm it's tight enough for most UK back boxes, but measure depth first if yours is already crowded with cabling.
In Home Assistant
| Control | Type | What it does |
|---|---|---|
| Switch | Switch | Single relay on/off for the load; no dimming. |
| Input 1 / Input 2 | Binary sensor / event | Two physical switch inputs, each independently configurable as push, toggle, or detached/edge mode; in detached mode they emit press events instead of directly driving the relay. |
| Signal strength | Sensor | Wi-Fi connection strength diagnostic. |
| Firmware update | Update | Surfaces available Shelly firmware releases, including the build needed to enable Matter. |
| Restart | Button | Reboots the device from HA without power-cycling the circuit. |
HA's shelly integration talks to the 1L Gen3 over Gen3 RPC/WebSocket, exposing one switch entity plus two independent input entities that can each be set to push, toggle, or detached/edge mode in the Shelly app — detached mode is what lets a two-gang stair switch fire HA automations without ever routing mains through the relay itself. There's no power or energy entity: because the 1L switches live-only with no neutral reference, the firmware doesn't compute wattage, so it won't populate the HA energy dashboard the way Shelly's PM-suffixed relays do. Matter ships as ready rather than active — the radio only turns on after a firmware update — and a good automation pairs one input in detached mode as a dedicated scene trigger, since the relay can't use power draw to distinguish a light physically on from a failed bulb the way a PM model could.
Specs
- channels
- 1
- max load
- 200W, bypass built in for loads over 5W
- weight g
- 24
- flush mount
- true
- dimensions mm
- 37x42x16
- rated voltage
- 220-240V~ 50Hz
- standby power w
- 1.2
- neutral required
- false
- operating temp c
- -20 to 40
