Sonoff
Sonoff SwitchMan ZBM5 Zigbee Wall Switch (2 Gang, 86-Type)
- Zigbee
Verified September 2026
Sonoff's flexible-wiring Zigbee switch: it detects whether you've got a neutral wire and adjusts its own operating mode, and in neutral mode it also doubles as a Zigbee router. Sold as a bare module behind an 86-type back box, not a finished faceplate, so budget for your own cover plate. The module measures 120×74×39.4mm — make sure your back box is at least 35mm deep before ordering. Load tops out at 10A resistive or 400W of LED per gang at 240V, with a 3W minimum draw required in no-neutral mode; Sonoff doesn't officially support smart bulbs on that wiring, and we haven't confirmed whether a bypass capacitor helps with flickery LED loads.
In Home Assistant
| Control | Type | What it does |
|---|---|---|
| Switch (per gang) | Switch | Per-gang relay on/off, each reporting its own state independently. |
| Operating mode | Sensor (read-only) | Reports end device or router — auto-selected by the module based on detected wiring, not settable from HA. |
| Detach relay (per gang) | Switch | Enabling a gang stops the physical button from switching its own relay so it can instead drive a scene/automation. |
| Network indicator | Switch | Turns the blue network-status LED on the module on or off. |
| Power-on behavior | Select | Sets relay state after a power loss (on/off/previous/toggle), per gang. |
The reported operating mode is read-only — HA only ever sees the module report back end device or router after it has already picked a mode from the wiring; there's no toggle to force it. On units installed without neutral, Zigbee2MQTT's post-pair configure step throws a benign cluster error while the mode reads end device — cosmetic and non-fatal, since on/off state, the physical button, power-on behaviour and the network indicator all keep working through it. Each gang also exposes a detach-relay setting that decouples the physical rocker from its own relay so a press only reports a state change instead of switching the load — a genuinely per-gang bitmask, letting you decouple one gang while leaving the other wired normally.
Specs
- gangs
- 2
- protocol
- Zigbee 3.0
- dimensions mm
- 120 x 74 x 39.4
- led load caveat
- No-neutral mode requires a minimum 3W load and does not officially support smart bulbs; bypass-capacitor need for flicker on non-smart LED loads not confirmed by Sonoff documentation
- neutral required
- false
- back box depth min mm
- 35
- min load no neutral w
- 3
- max load led w per gang
- 400W@240V / 200W@100V
- max load resistive a per gang
- 10
- zigbee router in neutral mode
- true
